070 TYPES
SERIES TERMINALS
| FIG |
PART
NO. |
METAL |
TREATMENT |
WIRE
RANGE
(mm2) |
Dimension
(mm) |
THICKNESS |
Q'TY |
REMARK |
| D |
H |
W |
L |
E |
| A |
918604T |
KS |
S |
0.3-0.5 |
/ |
2.7 |
2.7 |
18.1 |
6.7 |
0.25 |
4000 |
|
| A |
918605T |
KS |
S |
0.85-2.0 |
/ |
2.7 |
2.7 |
18.1 |
6.7 |
0.25 |
3000 |
|
| B |
918612T |
KS |
S |
0.85-2.0 |
/ |
2.7 |
2.7 |
18.0 |
7.1 |
0.25 |
3000 |
|
| B |
918613T |
KS |
S |
0.3-0.5 |
/ |
2.7 |
2.7 |
18.0 |
7.1 |
0.25 |
4000 |
|
| FIG |
PART
NO. |
METAL |
TREATMENT |
WIRE
RANGE
(mm2) |
Dimension
(mm) |
THICKNESS |
Q'TY |
REMARK |
| D |
H |
W |
L |
E |
| A |
918522T |
BS |
S |
0.85-2.0 |
/ |
0.6 |
1.9 |
25.9 |
8.9 |
0.3 |
4000 |
WATER-PROOF |
| A |
918523T |
BS |
S |
0.3-0.5 |
/ |
0.6 |
1.9 |
25.9 |
8.9 |
0.3 |
5000 |
WATER-PROOF |
| B |
918532T |
BS |
S |
0.85-2.0 |
/ |
0.6 |
1.9 |
27.0 |
8.0 |
0.3 |
5000 |
|
| C |
918552T |
BS |
5
S |
0.85-1.25 |
/ |
0.6 |
1.8 |
20.2 |
7.2 |
0.3 |
4000 |
WATER-PROOF |
| C |
918553T |
BS |
5
S |
0.3-0.5 |
/ |
0.6 |
1.8 |
20.2 |
7.2 |
0.3 |
4000 |
WATER-PROOF |
| D |
918622T |
PS |
S |
0.85-2.0 |
/ |
2.1 |
3.0 |
21.1 |
10.0 |
0.3 |
3000 |
WATER-PROOF |
| D |
918623T |
PS |
5
S |
0.3-0.5 |
/ |
2.1 |
3.0 |
21.1 |
10.0 |
0.3 |
3000 |
WATER-PROOF |
| E |
918632T |
PS |
S |
0.85-2.0 |
/ |
2.1 |
3.0 |
23.5 |
10.0 |
0.3 |
3000 |
|
| F |
918652T |
BS |
5
S |
0.5-1.25 |
/ |
2.5 |
2.8 |
16.6 |
6.9 |
0.3 |
4000 |
WATER-PROOF |
NEXT PAGE
|
