250 SERIES
CONNECTORS WITH LOCK ( HOUSINGS LANCE TYPE)
| FIG |
PART
NO. |
Dimension |
APPLICABLE
TERMINAL |
MATERIAL |
COLOR |
Q'TY/BAG |
REMARK |
| L |
H |
W |
| A |
SFCN-6BSPH |
25.00 |
12.00 |
28.00 |
904532T |
NL66 |
NATURE |
100 |
|
| B |
SFCN-8ASLH |
28.50 |
18.80 |
40.70 |
905512T |
NL66 |
NATURE |
100 |
|
| C |
SFCN-8BSLH |
25.00 |
12.00 |
36.80 |
904532T |
NL66 |
NATURE |
100 |
|
| D |
SFCN-10ASLH |
28.50 |
18.80 |
52.70 |
905512T |
NL66 |
NATURE |
50 |
|
| E |
SFCN-2BSPH |
24.70 |
15.20 |
10.00 |
904532T |
NL66(H) |
NATURE |
100 |
|
| F |
SFMICN-8MPH |
40.50 |
35.00 |
16.40 |
905512T |
NL66(H) |
NATURE |
100 |
|
| G |
SFMICN-8MH |
40.50 |
35.00 |
16.40 |
905512T |
NL66(H) |
NATURE |
100 |
|
